C.A.R.C. Chemical Agent Resistant Coating

OUR CARC PROCESS

Defense Grade Application Standards

At Colonial Surface Solutions, every Military CARC project follows a controlled, documented process designed to meet strict military specifications while ensuring long-term durability, corrosion resistance, and chemical agent protection.

SURFACE PREPARATION

Each part begins with a heated alkaline wash to remove oils, machining residues, and contaminants. This step ensures a clean surface that promotes proper adhesion and long-term coating performance.

VIRGIN BLAST

We perform a 60/80-mesh grit blast per TT-C-490 to achieve the required surface profile and cleanliness standards. Surface profile is verified to meet military requirements before advancing to the next stage.

CHEMICAL TREATMENT

Following blasting, parts undergo the appropriate chemical treatment based on substrate requirements. This may include alkaline washing, Alodine conversion coating, zinc phosphate, or passivation. All treatments are performed in compliance with TT-C-490 and MIL-DTL-5541.

PRIMER APPLICATION

Primers are applied in accordance with applicable military specifications, including MIL-DTL-53022, MIL-PRF-23377, and MIL-DTL-11414F. Using controlled paint application methods, we carefully monitor film build to ensure precision, durability, and compliance.

CARC TOPCOAT APPLICATION

CARC topcoats are applied in accordance with military standards such as MIL-DTL-24441, MIL-DTL-53039, MIL-DTL-53072, MIL-PRF-14105, and MIL-PRF-22750. Thickness is closely controlled to ensure uniform coverage, long-term performance, and chemical resistance.

CURING PROCESS

Parts can be cured in our inline forced-dry oven system to ensure proper coating performance. Larger components may undergo passive dry curing when required by size or specification.

INSPECTION & QUALITY CONTROL

Every part undergoes rigorous inspection and verification before release. We measure Wet Film Thickness (WFT) and Dry Film Thickness (DFT) after each coat, verify adhesion and cure. Our Quality Assurance program includes chemical monitoring, environmental monitoring and reporting, and 100% verification of parts prior to shipment.

shell carc coating
Tank emerging from building
Military carc coating 490

DEFENSE CARC CAPABILITIES

Quality. Precision. Compliance.

Colonial Surface Solutions is equipped to support both large-scale military programs and medium-capacity production runs.

DEFENSE PRODUCTION CAPABILITIES

We are set up to handle large military structures, such as Land System hulls and turrets, within a batch process. We also operate a medium-capacity production line with inline curing ovens, allowing us to efficiently process components of varying sizes. With over 20 years of military painting experience, our team understands the requirements of the defense industry.

ROBUST QUALITY ASSURANCE PROGRAM

Our Defense Division operates under a robust, structured Quality Assurance program designed to meet and exceed military standards.

THIS INCLUDES:

  • Substrate-specific testing evaluations
  • Monthly paint system evaluations
  • Environmental monitoring and reporting
  • Adhesion and cure verification
  • 100% part verification prior to release
  • ISO 9001 Certified since 2015
  • Partnered with an ISO 17025 accredited laboratory
  • ITAR Approved
We are committed to documented compliance and consistent performance on every project.

Military Specifications Supported

  • A-A-56032: Ink, Marking, Epoxy Base
  • A-A-59293: Sealing Compound, Adhesive: Curing
  • Mil-A-8625: Anodic Coatings for Aluminum and Aluminum Alloys
  • MIL-C-8514C: Pretreatment Wash Primer
  • MIL-DTL-24441D: Paint, Epoxy-Polyamide
  • MIL-DTL-11414F: Fast Dry Alkyd Primer
  • MIL-DTL-16232: Phosphate Coating, Heavy, Manganese or Zinc Base
  • MIL-DTL-53022: Primer, Epoxy Coating, Corrosion Inhibiting Lead and Chromate Free
  • MIL-DTL-53039: Coating, Aliphatic Polyurethane, Single Component, Chemical Agenty Resistant
  • MIL-DTL-53072: Chemical Agent Resistant Coating (CARC) System Application Procedures and Quality Control Inspection
  • MIL-DTL-5541: Chemical Conversion Coatings on Aluminum and Aluminum Alloys
  • MIL-PRF-14105: Paint, Heat-Resisting
  • MIL-PRF-22750: Coating, Epoxy, High-Solids
  • MIL-PRF-24712: Powder Coatings
  • MIL-PRF-32033: Lubricating Oil, General Purpose, Preservative
  • MIL-PRF-32348: Powder Coating, Camouflage Chemical Agent Resistant Systems
  • MIL-PRF-32550: Metal-Rich Primer
  • MIL-PRF-23377: Primer Coatings: Epoxy, High-Solids
  • MIL-PRF-24667: Coating System, Non-Skid, For Roll, Spray, or Self-Adhering Applications
  • MIL-STD-171: Finishing of Metal and Wood Surfaces
  • MS-51835: Insert and Stud, Locked In - Key Locked, Hole Dimensions For and Assembly Of
  • NASM33537: Insert, Screw Thread, Helical Coil, Inch Series, Course and Fine Thread
  • MIL-STD-130: Identification Markings of U.S. Military Property
  • MIL-AMS-S-880: Sealing Compound, Temperature-Resistant, Integral Fuel Tanks and Fuel Cell Cavities, High-Adhesion
  • SAE-AMS-STD-59: Tier II Adoption Notice: Colors Used In Government Procurement
  • TT-C-490: Cleaning Methods for Ferrous Surfaces and Pretreatments for Organic Coatings
Additional specifications available upon request.

Precision, Protection, and Pride in Every CARC Application

Reach out to our team to learn more about our CARC process and how we can support your project’s critical requirements.
